60-480kW DC Fast Charging Stations | High Power EV Chargers for Commercial

Next-generation DC fast charging powered by intelligent energy storage. Maximize fleet efficiency and minimize operational costs with our rapid, high-uptime stations.

Greenova DC fast charging – Key Features & Benefits

✅ OEM & ODM Support & Multi-Language Customization – Tailored solutions to meet diverse market needs.
✅ Rapid Charging Speed – Achieves 80% charge in just 20 minutes, providing quick turnaround for EV fleets.
✅ Universal Compatibility – Supports CCS, CHAdeMO, and GB/T standards for seamless charging across global EV models.
✅ Safety and Efficiency – With an efficiency over 95% and power factor above 0.98, the station also offers multiple layers of protection for user safety.
✅ Advanced Energy Storage – Integrated energy storage and smart inverter systems enhance operational efficiency.

Get A Free Quote

DC Fast Charging Station Description

Greenova DC Electric Vehicle Charging Station – Built for Public & Commercial Applications

Greenova, with 15 years of expertise in EV charger manufacturing, delivers state-of-the-art DC Fast Charging Stations designed to power the future of mobility.

Ultra-Fast Charging Performance
Charge EV batteries up to 80% in just 30 minutes, minimizing downtime and maximizing vehicle utilization.

Ideal for Multiple Scenarios
Perfect for public charging networks, fleet operators, logistics hubs, and commercial facilities, where reliability and quick turnaround are essential.

Customizable & Scalable Solutions
From 60kW to 480kW, our chargers are available with CCS2 / CHAdeMO options, OCPP compatibility, and modular power design — ensuring flexible deployment for both small and large-scale projects.

High-Speed DC EV Charger 60kW-480kW Ultra-Fast DC EV Charging Station | CCS2/CHAdeMO High Power Chargers for Highway & Fleets

Category	Model	GN-ENCMDC060-480K
input	Power Supply	3P+N+PE
	Battery Pack Voltage	380VAC+15%
	Frequency	45/65Hz
	THDi	≤ 5%
	Efficiency	≥ 95%
	Power Factor	≥ 0.99
Output	Connector Type	CCS1/CCS2/GB/T/CHAdeMO
	Voltage	200-1000VDC
	DC Current	200Amax/250A(Optional)
	Power Rating	60kw -480kw
	Voltage Accuracy	≤ 0.5%
	Current Accuracy	≥ +1%
General	HMI	12.0-Inch Touchscreen
	Charging Start Method	RFID Card/QR Code /Password
	Cable Length	5m
	Communication Protocol	OCPP 1.6J
	Operating Noise Level	≤ 75dB
	Ingress Rating	IP54
	IK Rating	IK10 (display is IK08)
	Power Meter	Accuracy Class 1.0 energy meter
	Enclosure	Galvanized steel, surface sprayed with anti-corrosion paint
	Place of Installation	Indoor / Outdoor
	Product Dimension(WDH)	8706022000mm 8907002100mm
	Package Dimension(WDH)	12709002200mm 129010002300mm
	Protection	Over Current,Under Voltage,Over Voltage,Short Circuit,ResidualCurrent,Surge Protection,Over Temperature
	Certification Standard	IEC 62196 2017, IEC 61851 2017, SAE J1772,CHAdeMO etc
	Network Connection	Cellular modem:WIFI 4GLAN:10/100 Base-T Ethernet
Environment	Operating temperature	-25° C~+55° C
	Storage temperature	-40° C~+75° C
	Maximum Installation Height	≤ 2000m
	Operating Humidity	5%~95% RH

Get A Free Quote Now

Products Categories

DC EV Chargering Station

AC EV Charger

Home AC EV Charger

Commercial AC EV Charger

AC Portable EV Charger

Split EV Charger

Battery Energy Storage System

Emergency Charging System

Get A Free Quote

DC EV Charger | Super Fast Charging Station / DC Fast EV Charger Applications

Optimized Applications of DC Fast Charging Stations

1. Public Charging Networks
Deploy in urban areas, highway rest stops, and city centers to provide reliable, rapid charging for EV drivers on the go.

2. Fleet Operations
Ideal for commercial fleets requiring high-throughput charging to minimize downtime and maximize vehicle availability.

3. Automotive Dealerships
Enhance customer experience with fast charging options, supporting test drives, sales, and service visits.

4. Corporate Campuses
Support sustainability goals and employee convenience by offering high-speed EV charging at workplace facilities.

5. Transportation Hubs
Install at airports, bus depots, and train stations to serve both public and commercial EVs with efficient turnaround charging.

6. Retail & Entertainment Venues
Attract and retain customers by providing fast charging services at shopping malls, restaurants, and leisure centers.

Product Specifications for DC Fast Charging Station Power Specifications

Input Connection 3-Phase :3P+N+PE
Input Voltage 400Vac+10%
Frequency 50Hz or 60Hz
THDi ≤5%
Power Factor ≥0.98
Output Voltage 150Vdc-1000Vdc
Max. Output Current 250A( 125A CHAdeMO )
Rated Power 40-480KW

User interface & contrcol

LCD Display 12.1 Color Touch Screen
User Authentication RFID(ISO/EC 14443)(APP/ Credit Card Customization )
LED Indicator Green/Blue/Red
Charger Connector CCS2(CCS1 /CHAdeMo Optional
Energy Measuring DC meter, with 1% accuracy

Communication

Backend Ethemet / Bluetooth / Wi-Fi ( 4G Optional )
Charging Protocol ISO 15118 , DIN 70121
Backend Protocol OCPP 1.6 J(OCPP2.x Coming soon)

Protection

Residual Current Device Yes
Internal Fuse Yes
Electrical Protection Over/Under Voltage Protection,Over Current Protection, Short Circuit Protection, Over/Under Temperature Protection, Lightning Protection, Ground Fault,Surge Protection

Environmental

Operating Temperature -30℃-+50℃
Storage Temperature -40℃-+75℃
Operating Humidity Max.93%RH,Non-Condensing
Operating Altitude ≤ 2000m
IP, lK Level IP54,IK10
Cooling Method Fan Cooling

Mechanical

Product Dimension 890*700*2100mm( W*D*H)
Package Dimension 1190*1190*2270mm( W*D*H)
Charging Cable Length 5m( Customizable )
Weight 400kg( Net )/470 kg( Gross )
Floor Standing
